MACHINE DESCRIPTION

SPINDLE DIAMETER

115 MM

TOOL TAPER

ISO 50

SPINDLE SPEED RANGE

1280 RPM

SPINDLE MOTOR

20 KW

X ( LONGITUDINAL TRAVEL )

2000 MM

ASSE Y (VERTICAL HEAD TRAVEL)

1500 MM

ASSE Z (CROSS TRAVEL )

1500 MM

ASSE W (SPINDLE TRAVEL)

900 MM

RAPID TRAVERSE: X-/Y-/Z-/W

2000 MM/MIN

TABLE SIZE

1220 X 1525 MM

TABLE LOAD

6 TON

WEIGHT APPROX.

18 TON

DIMENSIONS (L X W X H) APPROX.

4500 X 3000 X 2000 MM
