SPINDLE DIAMETER

130

TOOL TAPER

ISO 50

SPINDLE SPEED RANGE

900

SPINDLE MOTOR

18.5 kw

X ( LONGITUDINAL TRAVEL )

1500  MM

ASSE Y (VERTICAL HEAD TRAVEL)

2000 MM

ASSE Z (CROSS TRAVEL )

2200 MM

ASSE W (SPINDLE TRAVEL)

1000 MM

RAPID TRAVERSE: X-/Y-/Z-/W

5000 MM/1

TABLE SIZE

1800 X 2000 MM

TABLE LOAD

8 TON

WEIGHT APPROX.

37 TON
